Plywood
The plywood panels are glued crosswise with a water-resistant phenolic resin. The gluing meets the requirements of EN 314-2 class 3 – the highest gluing class for plywood in outdoor use.
Surface
The plywood panels are unsanded and not repaired with a C/C quality deck veneer.
The edges are not sealed.
Applications
The plywood panels are particularly suitable for moisture resistant solution in the packaging sector. In the construction sector, these plywood panels are useed for roof construction, roof extensions or wall construction . As a shuttering board it is designed for one time uses.
Plywood thickness
| Thickness in mm | Number of veneers | Weight in kg/m2 | Weight/pack in kg | Number of sheets /pack |
|---|---|---|---|---|
| 10 | 5 | 4,80 | 1520 | 101 |
| 12 | 5 | 5,76 | 1520 | 84 |
| 15 | 7 | 6,72 | 1520 | 72 |
| 18 | 9 | 8,32 | 1520 | 56 |
| 21 | 9 | 9,92 | 1520 | 48 |
| 24 | 11 | 11,20 | 1520 | 42 |
| 27 | 13 | 13,12 | 1520 | 36 |
| 30 | 13 | 14,08 | 1520 | 34 |
Other thicknesses on request
Plywood dimensions
1250 x 2500 mm/ 2500 x 1250 mm (only on request)
Tolerance length/width: according to EN 315
Wood moisture 10% +/- 2%
Structural properties
| Thickness in mm (EN 315) |
E-Modul in N/mm2 (EN 310) |
Bending strength in N/mm2 (EN 310) |
||
|---|---|---|---|---|
| Em5%II | Em5%┴ | fm5%II | fm5%┴ | |
| 15 | 3330 | 2766 | 32 | 28,5 |
| 18 | 3330 | 1946 | 31 | 29,7 |
| 21 | 4197 | 1943 | 31,3 | 23,3 |
Other panel thicknesses on request
FSC® or PEFC® compliant delivery is possible on request
