Plywood
The plywood panels are glued crosswise with a water-resistant phenolic resin. The gluing meets the requirements of EN 314-2 class 3 – the highest gluing class for plywood for outdoor use.
Surface
Phenolic resin film 120 g/m² on both sides
Other coatings on request.
Edge sealed with brown acrylic resin varnish.
Application/ Number of reuses
With optimal processing and proper treatment, up to 15 uses or more can be achieved.
However, this is a non-binding guide value that depends on many factors that affect tthe panel.
Plywood thickness
| Thickness in mm | Number of veneers | Weight in kg/m2 | Weight/pack in kg | Number of sheets/pack |
|---|---|---|---|---|
| 15 | 7 | 7,00 | 1520 | 67 |
| 18 | 9 | 8,30 | 1520 | 56 |
| 21 | 9 | 9,90 | 1520 | 48 |
Other thickness on request
Plywood dimesnion
1250 x 2500 mm/ 2500 x 1250 mm (only on request)
Tolerance length/width: according to EN 315
Wood moisture 10% +/- 2%
Structural properties
| Thickness in mm (EN 315) |
E-Modul in N/mm2 (EN 310) |
Bending strength in N/mm2 (EN 310) |
||
|---|---|---|---|---|
| Em5%II | Em5%┴ | fm5%II | fm5%┴ | |
| 15 | 3330 | 2766 | 32 | 28,5 |
| 18 | 3330 | 1946 | 31 | 29,7 |
| 21 | 4197 | 1943 | 31,3 | 23,3 |
Other panel thicknesses on request
FSC® or PEFC® compliant delivery is possible on request
